Genius Stack 105-229AS

BESS Air-Cooled

Home Product C＆I Energy Storage System

Smartly Built for Real Efficiency

With thoughtful engineering and proven technology, GS105-229AS offers stable, efficient, and safe energy storage — built to perform and easy to maintain.

Features

Long Cycle Life

6000-cycle-life safety LFP battery.

Intelligent Thermal Management

Intelligent fan control to support cell difference below 6 °C.

Redundant Control System

RTOS and Linux dual-system redundant control to prevent the shutdown of control system.

Advanced Fire Safety

Targeted cell-level fire suppression design to minimize fire risk from cell to system.

Flexible Cabinet Operation

Compatible with up to 10 battery cabinets in parallel operation and supports independent use of 1 to 2 cabinets.

Remote Maintenance

Remote Monitoring and Maintenance Platform for preventive maintenance, online system diagnosis, and OTA.

Technical Specifications

Rated Power	105 kW
Output Voltage Range	400 V / 230 V (-15 %~15 %)
Grid Frequency	50Hz / 60Hz
Power Factor	-1 ~ 1
Wiring Method	Three - phase Four - wire + PE
Rated Capacity	229kWh
Maximum Output Power	115kW ( Long - Term )
Operating Temperature	-20～55°C( >45°C derating ）
Protection Leve	IP54
Cooling Method	Industrial Air Conditioning + Forced Air Cooling
Total Efficiency	> 87 %
Fire Protection Method	Cell-level point-to-point perfluoroketone fire extinguishing + water firefighting (energy storage cabinet)
Certification	IEC 62619 , IEC60730-1 Appendix H, IEC61000-6-2 & IEC61000-6-4 , IEC 62477-1 , UN38.3 , EN 50549-1(PCS) , C10/11(PCS) , IEC61439-1 & IEC61439-2( Junction Cabinet )
Dimensions (WDH)	150012002280 mm
Weight	2650KG
